Three-Roller Non-Woven Fabric Winder

The three-roll surface winding assembly consists of a main drive roll, a nip roll (pressing roll), and a guide roll; winding is driven by friction generated through contact between the material and the drive roll surface, effectively flattening the wide fabric and minimizing wrinkles.

Supports extra-wide production with a maximum width of 7000 mm, making it suitable for large-scale geotextile and construction reinforcement material lines; the fabric flattening quality directly impacts the results of downstream coating or lamination processes.

The heavy-duty frame undergoes stress-relief annealing after welding and utilizes heavy-duty bearing housings to withstand high linear pressure and the weight of large rolls.

Offers selectable constant tension or taper tension modes, allowing the tension profile to be matched to material characteristics and accommodating the needs of both thick and medium-thickness fabrics.

Achieves a winding diameter of Φ1200 mm, meeting standard master roll specifications for most industrial fabrics and facilitating use in downstream coating or lamination processes.

Extra-wide winding of geotextiles for road construction and base fabrics for drainage boards in drainage systems; the finished roll width directly impacts on-site installation efficiency.

Heavy-duty winding of wide nonwovens for automotive interiors—such as headliners, carpet backings, and trunk liners—providing master rolls with uniform density for automated cutting lines.

Large-width production of industrial nonwovens for construction, including base fabrics for waterproofing membranes, thermal insulation materials, and sound barriers.
